Slim 650S NextGen V2 - Dimmable LED Grow Light - 650w (3 Dimmers) 3500K (UV/ir)
V2
USA Orders: 3-5 DAY Delivery
Europe & UK Orders: Ships within 1-2 business days
Canada & Japan Orders: Ships within 1-2 business days
international orders: Ships within 1-2 business days
253-881-1355 or inquire at Sales@OpticLEDGrowLights.com
Coverage Footprint:
Flower: Veg:
4' x 4' area (1.2m x 1.2m) 4' x 4' area (Up to 7' x 7' area)
Max: 5' x 5' area (1.5m x 1.5m)
(4' x 4' Grow Tent / 1.2m x 1.2m)
Hanging Height & Dimmer Settings :
Seedling: 48"+ / 25% Power
Vegetative: 48" + / 50% Power (or 24" @ 25% Power)
Flowering 4' x 4' area:
Wk1-3 - @30"-48" / 50% Power
Wk4-6 @24" - 36" / 75% Power
Wk7-8 @18" - 30" / 100% Power
Wk9-10 @12" - 24" / 100% Power
Pro Tips: It's always best to set the light up higher and let the plants grow up into the light.
Auto Sunrise from the v3 controller and monitoring Co2 will help you run at higher light intensity
(Owners Manual will guide you on dimmer settings)
Slim 750S Components:
LEDs: 3,168 Total LEDs
3500k White LEDs: 3,024 (6 LEDs per Watt)
- Top Bin Samsung Horticulture LM301H Series 3.14 umols/j 3500K Mixed White
Bloom Enhancers:
Deep RED LEDs: 112 pcs
- Samsung Horticulture LH351H V2 Deep Red LEDs - 3.8 umols/j (1.5w LED chips)
Blue LEDs: 32 pcs
Samsung Horticulture LH351H Royal Blue LEDs - 2.8 umols/j
Optics: 120 Degree Primary Lens on all LEDs (+ Conformal Coating)
(Secondary Optics is 120 Degree reflector built into the Heatsink
*optional clip on Lenses sold seperately - Required for Growers who use sprays
Drivers: Three 0%-100% Dimmable Drivers, Black Vented Housing.
Dimmers: 3 Independent Dimmers - 3 way Spectrum Controls
(Operate Manually or via the V3 Optic LED Master Controller)
Dimmer#1 (White LEDs Channel) - 495 watts
Dimmer#2 (RED Channel + UV & IR) - 105 watts
Dimmer#3 (Blue LEDs Channel) - 55 watts
Controller Tech: Fully Compatible - (*Touch Screen Controller is Sold Separately)
3 Way Dimmability - You can Control the 3 Dimmers Independently
Spectrum Control - 3 Way Spectrum Control, add more Red, White, or blue light independently or programmed in the timer mode.
Dual Port RJ-11 Controller hookup - Daisy chain up to 200 lights
Thermal management: Passive Cooling from a significantly Overbuilt extruded Heat sink (Fanless Technology - No Moving Parts)
*Coolest Operating Temp of any High Power Bar Fixture on the market.
Spectrum:
Full Spectrum White Light 3500k (Mixed White Light LEDs) (Full Power on 3 dimmers)
+ 660nm Deep RED + 450nm Royal Blue + ultraviolet + 730nm Far Red
Slim 650S NextGen V2 Spectrum:
Dimmer#1 - Full Spectrum White Light LEDs only
Dimmer#2 - + 660nm Deep RED
Dimmer#3 450nm Royal Blue
PPFD Slim 650S NextGen v2: 1,578
(tested with apogee mq-500 meter in 1.2m tent @669w)
6" Hanging Height PPFD: 1,578
12" Hanging Height PPFD: 1385
24" Hanging Height PPFD: 1054
36" Hanging Height PPFD: 875
Vertical PAR Penetration Chart - 6" - 48"
SLIM 650S NEXTGEN V2 Specifications:
Total LEDs: 3,168
Model of Samsung LEDs: Samsung LH351H V2 Deep Reds, LH351H Royal Blue, LM301H White LEDs.
PPFD @6": 1,578
ppf/w : 3.2 umols/J
ppf: 2,105 umols
Grams Per Watt: up to 3.0
Yield: up to 3.9 lbs in 4x4 (1.2m) / up to 4.41 lbs in 5x5 (1.5M)
HID/HPS equivalency: 1300 watts DE HPS
Kelvin: 3500K Day Light White + Deep Red + Royal Blue + UV + IR
IP Rating: IP67
Total LEDs : 3,168
Actual Max Power Draw: 669 watts max
Amps: 5.5 Amps at 120v ( 2.8 Amps @ 240v)
Voltage : Internationally Used 110 volts - 277volts
Warranty: 7 Year Warranty
Release Date: November 1st 2023
Shipping: Free Shipping in USA - International calculated at checkout
Light Fixture: 42" x 42" Vertical Farming Aluminum BAR Fixture - folds in half
Cables: 6 Foot attached power cord, 4 rope ratchets & 1 RJ-11 cable
Plug: USA, CANADA, EURO, Commercial, etc. (240v sold separately)
(We automatically ship the correct cord for your country)
Dimming: 3 Dimmer Knobs 0%-100%. 3-Way Spectrum Control
Spectrum Control: 3-Way Spectrum Control - Red + White + Blue
TouchScreen Master Controller: 2 ports to daisy chain multiple lights via RJ cable, Fully Compatible. 3 Dimmer control
Fixture Dimensions: 42" x 42" x 4.5"
Fixture Weight: 43 lbs (Aluminum Fixture + Driver Case)
Shipping Weight: 50 lbs
Hanger: Comes with 4 adjustable rope ratchet hangers.
Recommended for: Grow Tents, Grow Rooms, Greenhouses & Indoor Cultivations.
*International Shipments may require Taxes & Duties. Contact us for a quote!
Sales@OpticLEDGrowLights.com - CommercialGrower@OpticLEDGrowLights.com
Slim 650S NextGen Patent Pending
Videos:
Slim 650S NextGen V2 - Videos Page - Click Here
PPFD & PPF/W Testing Video:
Slim 650S NextGen LED Grow Light Review
Setting up the v3 Controller with Slim 650S -
